Double Deck Bottom Sealing Cutting Bag Machine
Double Deck Bottom Sealing Cutting Bag Machine
Characteristics
Descriptions:
Suitable material: HDPE, LDPE
The cutting machine is used to produce flat bag, shopping bag , it is belong to hot sealing cold cutting type. If add a manual or automatic puncher , it can produce t shirt bag/ vest bag ,supermarket shopping bag .
Feature:
China brand Touch screen computer control
Customized design 2 lines , 4 lines , 6 lines , 8lines
One line with photocell for making printed bag
Intelligent temperature control system
Static electricity elimination system
Optional Equipment:
1. Individual unwinding
2. AC Feeding motor
3. Yaskawa/Panasonic servo motor
4. Converyor
| SHXJ (4 Lines) | SHXJ ( 2 Lines) |
|
|
Technical parameter
| Model | SHXJ-600 | SHXJ-800 | SHXJ-1000 | SHXJ-1200 |
| Max.Width (mm ) | 550 | 750 | 950 | 1150 |
| Max.Length (mm) | 950 | 950 | 1200 | 2000 |
| Speed (pc/min) | 30- 120 | 30- 100 | 30- 100 | 30-80 |
| Feeding motor | 400w | 400w | 400w | 400w |
| Lines | 2 | 2/4 | 2/4/6 | 2/4/6/8 |
| Power of main motor(kw) | 1.5 | 1.5 | 1.5 | 1.5 |
| Weight(kg) | 800 | 1000 | 1200 | 1400 |
| Outline dimension (L×W×H) mm |
3200×1150×1550 | 3200×1350×1650 | 3200×1550×1750 | 3400×1750×1850 |
| Heating power (kw) | 4 | 5 | 6 | 6 |
Machines details
Production product display
