Biodegradable Film Blowing Machine
Description :
Suitable raw materials: PLA+PBAT+ starch + modified biodegradable raw materials.
the biodegradable film blowing machine is used to produce the biodegradable daily bags . Such as biodegradable shopping bag , biodegradable dog poop bag , biodegradable shopping bag, biodegradable supermarket bag .It can online with 2/4 color rotogravure printing machine to make printed biodegradable bag. As a plastic machinery manufacturer we should make a contribution to the cause of environmental protection in the society.
Feature:
Special design screw and barrel with high quality suitable for biodegradable material
Equipped with high efficient air ring cooling system, ensure good film thickness uniformity and high production efficiency
Centre winder type.
Optional Equipment:
1. Auto-loader
2. Corona treater
3. Rotary die head
4. Double winder
5. Online Printer
|
Model |
KP-BD50 |
KP-BD55 |
KP-BD60 |
|
Suitable material |
PO/PE/PLA+PBAT |
||
|
Film width(mm) |
600 |
800 |
1000 |
|
Max.Extrusion output(kg/hr) |
45-60 |
60-100 |
70-120 |
|
Screw diameter(mm) |
ф50 |
ф55 |
Ф60 |
|
Screw L/D length |
32:1 |
||
|
Screw material |
Bimetallic |
||
|
Cylinder material |
SACM-645/38CRMOALA |
||
|
Driving motor (kw) |
15 |
18.5 |
22 |
|
Die size(mm) |
Ф60/100/120 |
ф80/120/150 |
Ф80/200/220 |
|
Air ring |
1 ( three lip air ring) |
||
|
Air blower(kw) |
5.5kw |
7.5kw |
11kw |
|
Roller width(mm) |
700 |
900 |
1100 |
|
Height adjustable type |
/ |
||
|
Take-up speed(m/min) |
10-100 |
10-100 |
10-100 |
|
Take-up motor(kW) |
1.5 |
1.5 |
2.2 |
|
Winder Type |
Center rewinder with air shaft ,control by inverter |
||
 |
 |
 |
 |
 |
 |
