Automatic High Speed Vertaical Slitting and Rewinding Machine 400m/min
description1
Zipper closure 1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout
Characteristics

Descriptions:
Suitable material : BOPP,PEL,CPP,CPE,PVC, aluminium foil and paper
The slitting machine is suitable for separating and cutting such various roll material as BOPP,PEL,CPP,CPE,PVC, aluminium foil and paper,etc, and can cut edge, separate and cut materiel according to different requirements during production. This device has an optical tracking, automatic correcting, tension control, rolling count of the excellent performance, simple operation, stable and reliable. Mainly used in plastic film, cellophane, paper, aluminum foil decile cut.

Feature :
1. Unwinding : auto tension control with magnetic powder
2. Rewinding : asynchronous servo motor PLC control
3. Main motor 5.5kw : asynchronous servo motor

Technical parameters

Model

DFQ-1100

DFQ-1300

Max .width

1100mm

1300mm

Max.diameter of rewinding

Φ500

Φ500

Max.diameter of unwinding

Φ600

Φ600

Width of roll material cutting

30-1100mm

30-1300 mm

Inner Dia

3”-76mm

3”- 76mm

Separating and cutting speed

≤350m/min

≤350m/min

Machine Speed

≤450m/min

≤450m/min

Deviation-rectifying error

≤±0.3

≤±0.3

Main motor

5.5kw

5.5kw

Outline diameter(LXWXH)

3100x3000x2000mm

3100×3200×2000mm

Weight

2100kg

2200kg
