Descriptions:
The water cooling pelletizer recycling machine is suitable for regeneration and granulation of waste plastics,as HDPE,LDPE,and PP,etc.
It is equipped with motorized control or hydraulic screen changer, force feeder and automatic temperature control.
The granulating crusher uses adjustable speed motor,pelleting with an extruding machine at the same
discharging speed synchronistically.The unit is easy to operate,with a high output,steady performance,
and favorable economic benefit.
Feature:
1. Water cooling type
2. It is equipped with automatic constant temperature, motorized or hydraulic screen changer
3. the cutter is rotation type
4. Feeding unit adopts force feeder.
5. Screw and barrel are made of 38CrMoA1A with nitrogen treatment.
6. Single stage
Model |
KP-C100 |
KP-C110 |
KP-C120 |
Diameter of Screw |
100mm |
110mm |
120mm |
L:D |
20:1 |
20:1 |
20:1 |
Speed of Screw |
10-110rpm |
10-110rpm |
10-110rpm |
Gearbox |
173 |
180 |
200 |
Motor Power |
22kw |
30kw |
37kw |
Output |
90kg/h |
110kg/h |
130kg/h |
Water Tank Length) |
2500mm Stainless |
||
Screen changer |
Hydraulic/Motorized control |
||
Screen changer hole |
6mm |
||
Die head hole(Alloy Metal) |
4mm |
||
Cutter Knife |
Hobbing Cutter |
||
Machine Weight |
2000kg |
2200kg |
2500kg |
Overail Dimensions |
5.5*1.5*1.1m |
6*1.35*1.3m |
6.2*1.4*1.3m |
![]() |
![]() |
![]() |
![]() |
![]() |
