Plastic Film Edge Folding and Rolling Machine
Descriptions:
The edge folding and rolling machine is one parts of the side sealing machine, is suitable for folding BOPP sheet with such functions as automatic gluing,pearly-lustre film laminating,hobbling and longitudinal sealing(used together with ultrasonic) and opening breaking of roll material(the opening breaking mechanism can be equipped separately).
Feature:
Equipped with EPC , tension with magnetic powder
Optional Parts：
1. ir shaft
2. Ultrasonic
3. Auto feeding
|
Model |
600 |
700 |
800 |
900 |
1000 |
1 100 |
1200 |
|
Max rewinding width(mm) |
600 |
700 |
800 |
900 |
1000 |
1 100 |
1200 |
|
Max unwinding width(mm) |
1200 |
1400 |
1600 |
1800 |
2000 |
2200 |
2400 |
|
Max rewinding speed(m/min) |
60 |
60 |
60 |
60 |
55 |
45 |
35 |
|
General power(kw) |
2 |
2 |
2.5 |
2.75 |
3 |
3.5 |
4 |
|
Weight of whole machine(kg) |
400 |
450 |
500 |
550 |
650 |
750 |
850 |
 |
 |
 |
